200mm Clear Lens RYG Full Ball LED Traffic Light

Key Features:

• Wide Operating Voltage: The traffic light operates on a broad voltage range of AC 85V-265V and DC 10-30V, ensuring stable and reliable performance across different power grids.

• Optimal Optical Performance:

  • Features a transparent, impact-resistant polycarbonate optical lens for maximum durability and clear signal projection.

  • The specialized design minimizes the "anti-phantom" effect, preventing false signals from sunlight and external light sources, while providing an optimal viewing angle.

  • Compliant with the EN12368 standard, it offers a viewing distance of over 300 meters for enhanced road safety.

• High-Intensity, Energy-Efficient LEDs:

  • Utilizes high-intensity 5mm DIP (Dual In-line Package) LED light sources from EPISTAR for brilliant, unmistakable signaling.

  • With a power factor greater than 0.9, it is designed for low energy consumption, reducing operational costs and environmental impact.

• Exceptional Longevity: The unit boasts a working life cycle of over 80,000 hours, significantly extending its service life and minimizing maintenance and replacement expenses.

• Durable and Weather-Resistant Construction:

  • The housing is constructed from highly durable, UV-stabilized polycarbonate, offering excellent resistance to harsh weather conditions and sunlight exposure.

  • The unit is rated for a wide operational temperature range of -40°C to +80°C, conforming to EN12368 Class A, B, and C classifications.

  • Available in a standard black housing, with fir-green and yellow options available for bulk orders.

• Modular and User-Friendly Design:

  • Its modular design simplifies installation and maintenance.

  • An easy-to-use snap-in open system provides quick access to internal components.

• Flexible Mounting: The included L-shaped and arm-shaped mounting brackets provide versatile and secure installation options.

• Certified Quality: This product is fully compliant with major quality and safety standards, including CE, RoHS, EN12368, and ISO9001.

Technical Specifications:

• Diameter: ϕ 200mm

• LED Type: 5mm DIP

• Optical Performance: Conform to EN12368 standard

• View Distance: ≥300m

• Input Voltage: AC 85V-265V, DC 10-30V

• Power Factor: > 0.9

• Working Temperature: $-40^{\circ}$C ∼ $+80^{\circ}$C

• Material (Lens/Housing): UV-stabilized polycarbonate

• Housing Color: Black (standard); fir-green/yellow available upon quantity request

Packaging Information:

• Carton Size: 97 x 37 x 28 cm

• Quantity: 1 set/carton

• Net Weight: 8.5 kg

• Gross Weight: 9.8 kg

• Volume: 0.1 m³

Included Components:

• Housing

• Visors & Brackets
